3004 Aluminum Alloy

Alloy 3004 is commonly used in the production of beverage cans as its combination of formability and corrosion resistance makes it ideal for this application.

Table of Contents
  1. Haomei Aluminum 3004 Aluminum Hot Products
  2. 3004 Aluminum Features
  3. 3004 Aluminum Alloy Product Forms
  4. 3004 Aluminum Standards
  5. 3004 Aluminium Alloy Composition
  6. 3004 Aluminum Uses
  7. Related Questions for 3004 Aluminum
  8. 3004 Aluminum Related Topics
  9. Popular 3004 Aluminium Blogs
  10. Aluminium Alloy Table

3004 aluminum alloy is a deformed aluminum-manganese alloy with good formability, high corrosion resistance, and medium strength.

3004 alloy was developed to meet the demand for thinner gauges in can materials, thereby replacing to some extent its predecessor 3003 alloy in beverage can manufacturing.

Due to the addition of 1% magnesium in 3004 aluminum, the can blank can be made thinner, which helps solid solution strengthening.

Haomei Aluminum 3004 Aluminum Hot Products

3004 Aluminum Features

3004 has higher strength than 3003 and is used for parts that require higher strength than 3003 alloy.

  • Can be cold processed
  • Heat treatment is not possible)
  • Usually rolled and extruded
  • Usually not forged
  • it is not used for casting

3004 Aluminum Alloy Product Forms

Product Form Application
3004 Aluminum Sheet Beverage cans, cooking utensils, roofing
3004 Aluminum Coil Automotive parts, can bodies, general sheet metal
3004 Aluminum Plate Pressure vessels, marine applications
3004 Aluminum Foil Packaging, insulation, decorative elements
3004 Aluminum Bar General fabrication, components, hardware
3004 Aluminum Tube Heat exchangers, tubing for fluid transport
3004 Aluminum Extrusions Architectural components, framing
3004 Aluminum Casting Engine components, decorative elements
3004 Aluminum Forgings Aerospace components, high-stress applications

3004 Aluminum Standards

  • ASTM B209: Standard Specification for Aluminum and Aluminum Alloy Plate and Plate
  • ASTM B221: Standard Specification for Aluminum and Aluminum Alloy Extruded Rods, Bars, Wire, Shapes, and Tubing
  • ASTM B547: Standard Specification for Formed and Arc Welded Round Pipe of Aluminum and Aluminum Alloys
  • ISO 6361: Wrought aluminum and aluminum alloy plates, strips and plates

3004 Aluminium Alloy

Use cold working methods to improve its mechanical properties:

  • High plasticity in the annealed state
  • Good plasticity during semi-cold work hardening
  • Low plasticity during cold work hardening

3004 Aluminium Alloy Composition

Element Composition Range (Mass %)
Al (Aluminum) 95.6 to 98.2%
Mg (Magnesium) 0.8 to 1.3%
Si (Silicon) 0.3% max
Fe (Iron) 0.7% max
Cu (Copper) 0.25% max
Zn (Zinc) 0.25% max
Mn (Manganese) 1.0 to 1.5%
Remainder 0.15% max (Impurities and other elements)

3004 Aluminum Uses

Mainly used for applications requiring high plasticity and good weldability.

  • Low load parts working in liquid or gaseous media, such as mailboxes, gasoline or lubricating oil conduits.
  • Various liquid containers and other small load parts made by deep drawing.
  • Wire used to make rivets

Choose 3004 aluminum when the following requirements are required at the same time:

  • 1. Processing requires parts with good formability, high corrosion resistance and good weldability.
  • 2. Work requiring higher strength than 1XXX series alloys

Specific examples include:

  • kitchen utensils
  • heat sink
  • beverage cans
  • Colored aluminum plate
  • lamp holder
  • vanity board
  • Photocopier roller
  • Ship materials
  • Building materials
  • building baffles
  • Cable duct
  • sewer
  • Various lighting parts
  • What is aluminum alloy 3004 made of?
  • What is the difference between 3003 and 3004 aluminum?
  • Is aluminum 3004 machinability?
  • What is the toughest Aluminium alloy?
  • What is the highest grade of aluminum?
  • What is the cheapest grade of aluminum?
  • aluminium alloy 3004 material properties
  • aluminum 3004 vs 6061
  • aluminum 3004 mechanical properties
  • aluminium alloy 3004 chemical composition
  • aluminum alloy 3004 melting point
  • aluminum alloy (al) 3004 price
  • 3004 aluminum sheet
  • 3004 aluminum scrap price
  • 3004 aluminum young's modulus
  • 5182 aluminum
  • 3004 Aluminum Rivets Wire
  • 3004 H19 Aluminum Coil Strip for Can Body

Aluminium Alloy Table

Al 1000 series (Pure) 1050, 1060, 1070, 1100, 1145, 1200, 1230, 1350
Al-Cu 2000 series 2011, 2014, 2017, 2024, 2124, 2219, 2319, 2397, 2519, 2524, 2618
Al-Mn 3000 series 3003, 3004, 3005, 3104, 3105
Al-Si 4000 series 4006, 4007, 4015, 4032, 4043, 4047, 4543
Al-Mg 5000 series 5005, 5019, 5050, 5052, 5059, 5083, 5086, 5154, 5182, 5252, 5356, 5454, 5456, 5754
Al-Mg-Si 6000 series 6005, 6010, 6013, 6060, 6061, 6063, 6065, 6082, 6101
Al-Zn 7000 series 7005, 7010, 7022, 7034, 7039, 7046, 7050, 7055, 7065, 7072, 7075
8000 series (Misc.) 8006, 8009, 8011, 8014, 8019, 8025, 8030, 8090, 8091, 8093, 8176
