1100 Aluminum Alloy

1100 aluminum alloy is an aluminum-based alloy in the "commercially pure" forged series (1000 or 1xxx series). It contains at least 99.0% aluminum, the highest alloy content in the 1000 series.

Table of Contents
  1. 1100 Aluminum Alloy Advantages
  2. Haomei Aluminum 1100 Aluminum Hot Products
  3. 1100 Aluminum Alloy Features
  4. 1100 Aluminum Mechanical Properties
  5. 1100 Aluminum Chemical Composition
  6. 1100 Aluminum Applications
  7. 1100 Aluminum Similar Grades
  8. Related Questions for 1100 Aluminum
  9. 1100 Aluminum Related Searches
  10. Customer Order for 1100 Aluminum
  11. Popular 1100 Aluminium Blogs
  12. Aluminium Alloy Table

The process performance of 1100 aluminum is basically the same as that of 1050A. 1100 aluminum is the alloy with the strongest mechanical properties in the 1000 series and is also the only 1000 series alloy commonly used for rivets.

1100 Aluminum Alloy Advantages

  • High conductivity
  • thermal conductivity
  • Corrosion resistance
  • Processability

Haomei Aluminum 1100 Aluminum Hot Products

1100 Aluminum Alloy Features

  • 1100 aluminum can be hardened by cold working,
  • 1100 aluminum cannot be hardened by heat treatment.
  • Anodizing 1100 aluminum can further improve corrosion resistance while obtaining a beautiful surface.

1100 Aluminum Mechanical Properties

  • Tensile strength σb (MPa): 110~136
  • Elongation δ10 (%): 3~5

1100 Aluminum Chemical Composition

The alloy composition of 1100 aluminum is:

  • Aluminum: 99.0–99.95%
  • Copper: 0.05–0.20%
  • Iron: 0.95% max
  • Manganese: 0.05% max
  • Silicon: 0.95% max
  • Zinc: 0.1% max
  • Residuals: 0.15% max

1100 Aluminum Alloy

1100 Aluminum Applications

  • 1100 Aluminum for heat sink
  • 1100 Aluminum for bottle caps
  • 1100 Aluminum for printing plates
  • 1100 Aluminum for deep drawing products
  • 1100 Aluminum for cookware
  • 1100 Aluminum for heat exchanger components
  • 1100 Aluminum for building materials
  • 1100 Aluminum for utensils

1100 Aluminum Similar Grades

  • International standard: Al99.0 (ISO)
  • Japan: Al100/Al00 (JIS)
  • European Standard: EN AW 1100 (EN)
  • France: A45
  • Canada 990C (CSA)
  • United States: 1100 (AA)
  • What is 1100 grade aluminum?
  • What is the difference between 1100 and 6061?
  • What is the Aluminum alloy 1100 equivalent to?
  • Does 1100 aluminum work harden?
  • 1100 Aluminum Sheet
  • 1100 Aluminum Foil
  • 1100-H14
  • 3003 aluminum
  • 6061 aluminum
  • 5083 Aluminum
  • 2024 Aluminum

Customer Order for 1100 Aluminum

  • 1100 H14 H18 Aerospace Aluminum Bar
  • 1100 O/H14/H18/H112 Aerospace Aluminum Tube Pipe
  • 1100 H112 Automotive Flat Aluminum Tube
  • 1100 O/H14 Aerospace Aluminum Sheet and Plate
  • 1100 H18 Aluminum Corrugated Preprinted Sheet
  • 1100 PCB Aluminum Entry Sheet
  • 1100 Automotive Aluminum Embossed Heat Shield Sheet
  • 1100 H112 Automotive Aluminum Tube Coil
  • Capacitor Aluminum Foil 1100
  • 1100 Aluminum Rod for Fasteners
  • 1100 O H12 H14 H16 Aerospace Aluminum Wire

Aluminium Alloy Table

Al 1000 series (Pure) 1050, 1060, 1070, 1100, 1145, 1200, 1230, 1350
Al-Cu 2000 series 2011, 2014, 2017, 2024, 2124, 2219, 2319, 2397, 2519, 2524, 2618
Al-Mn 3000 series 3003, 3004, 3005, 3104, 3105
Al-Si 4000 series 4006, 4007, 4015, 4032, 4043, 4047, 4543
Al-Mg 5000 series 5005, 5019, 5050, 5052, 5059, 5083, 5086, 5154, 5182, 5252, 5356, 5454, 5456, 5754
Al-Mg-Si 6000 series 6005, 6010, 6013, 6060, 6061, 6063, 6065, 6082, 6101
Al-Zn 7000 series 7005, 7010, 7022, 7034, 7039, 7046, 7050, 7055, 7065, 7072, 7075
8000 series (Misc.) 8006, 8009, 8011, 8014, 8019, 8025, 8030, 8090, 8091, 8093, 8176

Related Topics: heat sinks Aluminium Cookware Aluminum bottle caps Aluminium bottle cap packaging Aluminum building Aluminum
