2024 Aluminum Alloy

Aluminum Alloy 2024 is a high-strength, heat-treatable aluminum alloy that is part of the 2000 Series. It is composed primarily of copper (about 4.4%), with smaller amounts of manganese (1.5%), magnesium (1.2%), and trace amounts of other elements.

Table of Contents
  1. 2024 Aluminum Alloy Features
  2. Haomei Aluminum 2024 Aluminum Hot Products
  3. 2024 National Standard Implementation Standard
  4. 2024 Aluminum Spot Specifications
  5. 2024 Aluminum Alloy Product Forms
  6. Typical Temper 2024 Aluminum
  7. 2024 Aluminum Mechanical Properties
  8. 2024 Aluminum Physical Properties
  9. 2024 Aluminum Chemical Composition
  10. 2024 Aluminum Heat Treatment
  11. 2024 Aluminum Applications
  12. 2024 Aluminum Related Searches
  13. Related Questions for 2024 Aluminum
  14. Recently Completed Orders for 2024 Aluminum
  15. Popular 2024 Aluminium Blogs
  16. Aluminium Alloy Table

Aluminum Alloy 2024 is a high-strength, heat-treatable aluminum alloy that is part of the 2000 Series. It is composed primarily of copper (about 4.4%), with smaller amounts of manganese (1.5%), magnesium (1.2%), and trace amounts of other elements.

2024 Aluminum Alloy Features

  • It has high strength and certain heat resistance, and can be used as working parts below 150°C.
  • At temperatures above 125°C, the strength of 2024 alloy is higher than that of 7075 alloy.
  • 2024 is typically extruded and is also available in aluminized sheet and plate form.
  • 2024 aluminum can only be welded via friction welding and has average machining properties.

Haomei Aluminum 2024 Aluminum Hot Products

2024 National Standard Implementation Standard

Due to its poor corrosion resistance, 2024 aluminum is often protected by aluminum or Al-1Zn coating, but this may reduce fatigue strength.

  • GB/T3880.2-2006 (non-aluminum clad)
  • AMS-QQ-A-250/5 (aluminum clad)

2024 Aluminum Spot Specifications

  • 2024 Aluminum Sheet Plate spot specifications: 0.3mm-350mm (thickness)
  • 2024 Aluminum Bar spot specifications: 3.0mm-500mm (diameter)
  • 2024 Aluminum Wire spot specifications: 0.1mm-20mm (wire diameter)

2024 Aluminium Alloy

2024 Aluminum Alloy Product Forms

Product Form Application
2024 Aluminum Sheet Roofing, signage, electronic casings
2024 Aluminum Coil Building materials, automotive parts
2024 Aluminum Plate Aerospace components, marine applications
2024 Aluminum Foil Packaging, insulation, decorative elements
2024 Aluminum Bar Structural components, fasteners, hardware
2024 Aluminum Wire Electrical wiring, conductors, fastening
2024 Aluminum Tube Heat exchangers, tubing for fluid transport
2024 Aluminum Extrusions Window frames, door frames, structural elements
2024 Aluminum Casting Engine components, decorative elements
2024 Aluminum Forgings Aircraft components, high-stress applications

Typical Temper 2024 Aluminum

  • 2024-O Aluminum
  • 2024-T3 Aluminum
  • 2024-T4 Aluminum
  • 2024-T5 Aluminum
  • 2024-T351 Aluminum

2024 Aluminum Mechanical Properties

  • Tensile strength σb (MPa) ) ≥425
  • Conditional yield strength σ0.2 (MPa) )≥275

2024 Aluminum Physical Properties

  • Density of 2.78 g/cm3 (0.1 lb/in3)
  • Electrical conductivity of 30% IACS
  • Young's Modulus of 73 GPa

2024 Aluminum Chemical Composition

The alloy composition of 2024 is:

  • Aluminium (90.7–94.7%)
  • Silicon no minimum, maximum 0.5% by weight
  • Iron no minimum, maximum 0.5%
  • Copper minimum 3.8%, maximum 4.9%
  • Manganese minimum 0.3%, maximum 0.9%
  • Magnesium minimum 1.2%, maximum 1.8%
  • Chromium no minimum, maximum 0.1%
  • Zinc no minimum, maximum 0.25%
  • Titanium no minimum, maximum 0.15%
  • Other elements no more than 0.05% each, 0.15% total

2024 Aluminum Heat Treatment

  • The heat treatment strengthening effect of 2024 aluminum is significant, but the heat treatment process requirements are strict.
  • The corrosion resistance is poor, but it can be effectively protected by coating with pure aluminum.
  • Cracks are prone to occur during welding, but special processes can be used to weld or rivet them.

2024 Aluminum Applications

Used extensively in aerospace applications including aircraft structures and components.

  • aircraft structure
  • wing
  • body
  • Skin
  • skeleton
  • Rib beam
  • partition frame
  • other
  • truck hub
  • rivet
  • missile structure
  • propeller elements
  • various structures
  • 2024 aluminium alloy composition
  • 2024 aluminium sheet
  • 2024 aluminium alloy properties
  • 2024 aluminium bar
  • 2024 aluminium tube
  • 2024 aluminium alloy aircraft
  • 2024 aluminium rod
  • 2024 aluminium alloy used for
  • 2024 aluminium extrusion
  • Differences Between 2024 vs 7075 Aluminum Alloy
  • What is 2024 aluminum made of?
  • What is the difference between 2024 and 7075 aluminum alloy?
  • Is 2024 stronger than 6061?
  • What is the difference between aluminum 2024 and 2124?

Recently Completed Orders for 2024 Aluminum

  • 2024 T3 T4 Aircraft Aluminum Sheet Plate
  • 2024 T3 T4 T351 Aluminium Sheet Plate
  • 2024 O/T4 Aluminum Sheet for Auto Body
  • 2024 Cold Drawn Aluminum Tubing
  • 2024 T3/T351 Aerospace Aluminum Rod Bar
  • 2024 Quenched Pre-stretched Aluminum Plate
  • 2024A O/T3/T8/T351 Aerospace Aluminum Extrusion
  • 2024 Aluminum Square Tube
  • 2024 Aluminum Alloy Wire for Rivets
  • 2024 Aluminum Bar
  • 2024 Aluminum Round Bar
  • AMS 2024 T3 T4 Aircraft Drawn Aluminum Tube
  • 2024 T3/T4/T351/T851/O Aerospace Aluminum Wire
  • 2024 T3 T351 T851 Aerospace Aluminum Foil
  • 2024A T6/T8/T851 Automotive Aluminum Extrusion
