6061 Aluminum Alloy

6061 aluminum alloy is a high-quality aluminum alloy product produced by heat treatment and pre-stretching process.

Table of Contents
  1. 6061 Aluminum Features
  2. Haomei Aluminum 6061 Aluminum Hot Products
  3. 6061 Aluminum Alloy Product Forms
  4. Typical Supply Status of 6061 Aluminum
  5. 6061 Aluminum Spot Specifications
  6. 6061 Aluminum Mechanical Properties
  7. 6061 Aluminium Alloy Chemical Composition
  8. 6061 Aluminum Processing Methods
  9. Corresponding Grades of 6061 Aluminum
  10. 6061 Aluminum Calculation Method
  11. 6061 Aluminum Applications
  12. Related Questions for 6061 Aluminum
  13. Related Questions for 6061 Aluminum
  14. Newest Order for 6061 Aluminium
  15. Aluminium Alloy Table

6061 Aluminum Features

  • Excellent processing performance
  • Good corrosion resistance
  • High toughness
  • No deformation after processing
  • Easy to apply color film
  • Excellent oxidation effect

Haomei Aluminum 6061 Aluminum Hot Products

6061 Aluminum Alloy Product Forms

  • 6061 Aluminum Sheet
  • 6061 Aluminum Plate
  • 6061 Aluminum Extrusions
  • 6061 Aluminum Bars and Rods
  • 6061 Aluminum Forgings
  • 6061 Aluminum Tubes and Pipes
  • 6061 Aluminum Welded Assemblies
  • 6061 Aluminum Wire
  • 6061 Aluminum Castings
  • 6061 Aluminum Discs
  • 6061 Aluminum Strips
  • 6061 Aluminum Coils

Typical Supply Status of 6061 Aluminum

  • 6061-O Aluminum
  • 6061-T6 Aluminum
  • 6061-T651 Aluminum

6061 Aluminium Alloy

6061 Aluminum Spot Specifications

  • 6061 aluminum plate spot specifications: 0.3mm-500mm (thickness)
  • 6061 aluminum rod spot specifications: 3.0mm-500mm (diameter)
  • 6061 aluminum wire spot specifications: 0.1mm-20mm (wire diameter)

6061 Aluminum Mechanical Properties

  • The ultimate tensile strength of 6061 is more than 205 MPa
  • Compressive yield strength 55.2 MPa
  • Elastic coefficient 68.9 GPa
  • Bending ultimate strength 228 MPa
  • Bending Yield Strength 103 MPa

6061 Aluminium Alloy Chemical Composition

Element Composition (%)
Magnesium 1.0-1.2
Silicon 0.6-0.8
Copper 0.25
Chromium 0.15-0.35
Iron 0.04-0.35
Manganese Less than 0.15
Zinc Less than 0.15
Titanium Less than 0.15
Others Less than 0.05 each, Less than 0.15 total

6061 Aluminum Processing Methods

  • extrusion
  • forging
  • casting

Corresponding Grades of 6061 Aluminum

  • ISO: AlMg1SiCu ISO 209.1-1989
  • Japanese standard: A6061 JIS H4000-1999 JIS H4040-1999
  • Non-standard: 65032 IS 733-2001 IS 737-2001
  • EN: EN AW-6061/AlMg1SiCu EN 573-3-1994
  • German standard: AlMgSi1Cu/3.3211 DIN 1725.1-1986/W-Nr
  • French standard: 6061 A-GSUC NF A50-411 NF A50-451
  • British Standard: 6061 N20/H20 BS 1470-1988
  • American Standard: 6061/A96061 AA/UNS
  • National standard: 6061 LD30 GB/T 3190-2008

6061 Aluminum Calculation Method

Aluminum plate weight (kg) = 0.00000275 × thickness × width × length unit (mm)

Aluminum tube weight (kg) = 0.00000275 × (outer diameter × outer diameter - inner diameter × inner diameter) x 3.14/4 × length unit (mm)

Aluminum rod weight calculation formula (kg) = 0.00000275 × 3.14 × radius × radius × length unit (mm)

6061 Aluminum Applications

Aerospace Components: 6061 aluminum is used in the construction of aircraft structures, including wings, fuselages, and other components.

Automotive Parts: This alloy is employed in the manufacturing of automotive parts such as frames, panels, and wheels.

Bicycle Frames: Many high-performance bicycle frames are made from 6061 aluminum due to its strength, durability, and light weight.

Marine Components: 6061 aluminum is corrosion-resistant, making it suitable for marine applications like boat hulls, masts, and other components exposed to saltwater environments.

Structural Components: The alloy is commonly used in the construction of structural components for buildings, bridges, and other infrastructure due to its high strength and weldability.

Sporting Goods: 6061 aluminum is used in the production of various sporting goods, including baseball bats, golf clubs, and camping equipment, owing to its lightweight and durable properties.

Electronic Enclosures: The alloy is used for electronic enclosures and cases due to its good electrical conductivity and ability to dissipate heat.

Firearms Components: Some firearm components, such as rifle receivers and pistol frames, are made from 6061 aluminum due to its strength and lightweight characteristics.

Machined Parts: 6061 aluminum is commonly used in the production of machined parts and components in various industries due to its excellent machinability.

Heat Sinks: Its good thermal conductivity makes 6061 aluminum suitable for heat sinks, which are used to dissipate heat from electronic components.

Mold Making: The alloy is used in some mold making applications due to its machinability and corrosion resistance.

Food and Beverage Cans: While not as common as other aluminum alloys like 3003, 6061 can be used in the manufacturing of certain types of food and beverage cans.

  • What is 6061 Aluminium alloy used for?
  • Is 6061 aluminum as strong as steel?
  • Is 6061 aluminum good?
  • What is the equivalent of 6061 Aluminium?
  • 6061 vs 6063 aluminium
  • 6061 t6 aluminium
  • 6061 vs 5083 aluminium
  • 6061-t6 aluminium alloy
  • 6061 vs 6082 aluminium
  • 6061 vs 6066 aluminium
  • 6061 vs 7075 aluminium
  • 6061 t6 aluminium properties
  • 6061 vs 5052 aluminium
  • 6061 grade aluminium

Newest Order for 6061 Aluminium

  • 6061 Aluminum Sheet Plate
  • 6061 T4 Electrical Aluminum Busbar
  • 6061 Oil Tanker Aluminum Tube
  • 6061 Aluminum Pneumatic Cylinder Tube
  • Automotive 6061 Aluminum Wheel Hub Forging Supplier
  • 6061 Aluminum Tubing
  • 6061 T4 T5 T6 Cabinet Handle Aluminum Profile
  • 6061 Marine Aluminum Round Bars
  • 6061 T651 Aluminum Sheet Aerospace Grade
  • 6061 T4/T5/T6 Aluminum Automotive Profile
  • 6061 Cold Drawn Aluminum Tubing
  • 6061 T6 T6511 Aluminum Hex Bar
  • 6061 Aluminum Wire Rod for Rivets
  • AMS 6061 Drawn Seamless Aluminum Tube Aircraft Grade
  • 6061 7001 7075 Telescoping Aluminum Tent Pole
  • 6061 Aluminum Round Bar
  • 6061 T6 Aluminum Street Light Pole
  • Marine Grade 6061 Aluminum Hexagonal Bar
  • 6061 T6/T451/T4 Aerospace Grade Aluminum Forgings
  • 6061 Aerospace Aluminum Bar Rod
  • 6061 O T4 T6 3C Digital Shell Aluminum Sheet
  • 6061 O/T4/T6 Aerospace Aluminum Wire
  • 6061 T6 Aluminum Tube for Bicycle Frame
  • 6061 O/T6/T4/ T3511/T8511 Marine Aluminum Square Bar for Shipbuilding
  • 6061 Aluminum Extruded Profiles for Aluminum Bridges
  • 6061 Aluminum Bar
  • 6061 O/T4 Automotive Body Sheet Metal
  • 6061 Aluminum Flat Bar
  • 6061 T6/T4/T4511/T6511 Extruded Aluminum Profile for Aerospace
  • 6061 T6 Conductive Aluminum Tubular Buspipe
  • 6061 Aluminum Square Bar
  • 6061 T6 Aluminum Square Tubing
  • 6061 T6 Aluminum Forging for Auto

Aluminium Alloy Table

Al 1000 series (Pure) 1050, 1060, 1070, 1100, 1145, 1200, 1230, 1350
Al-Cu 2000 series 2011, 2014, 2017, 2024, 2124, 2219, 2319, 2397, 2519, 2524, 2618
Al-Mn 3000 series 3003, 3004, 3005, 3104, 3105
Al-Si 4000 series 4006, 4007, 4015, 4032, 4043, 4047, 4543
Al-Mg 5000 series 5005, 5019, 5050, 5052, 5059, 5083, 5086, 5154, 5182, 5252, 5356, 5454, 5456, 5754
Al-Mg-Si 6000 series 6005, 6010, 6013, 6060, 6061, 6063, 6065, 6082, 6101
Al-Zn 7000 series 7005, 7010, 7022, 7034, 7039, 7046, 7050, 7055, 7065, 7072, 7075
8000 series (Misc.) 8006, 8009, 8011, 8014, 8019, 8025, 8030, 8090, 8091, 8093, 8176
