7050 Aluminum Alloy

7050 aluminum alloy is a high-strength heat-treatable alloy with extremely high strength and resistance to spalling corrosion and stress corrosion cracking. Commonly used in aircraft structural parts for medium and thick plate extrusions, free forgings an

Table of Contents
  1. 7050 Aluminum Alloy Features
  2. Haomei Aluminum 7050 Aluminum Hot Products
  3. 7050 Aluminum Alloy Product Forms
  4. 7050 Aluminum Alloy Physical Properties
  5. 7050 Aluminum Alloy Composition
  6. 7050 Aluminum Applications
  7. Eq to 7050 Aluminum
  8. Related Questions for 7050 Aluminum
  9. 7050 Aluminum Related Topics
  10. Latest Order for 7050 Aluminum
  11. Aluminium Alloy Table

7050 Aluminum Alloy Features

  • high strength
  • High toughness
  • Fatigue resistant
  • Damage resistant

Haomei Aluminum 7050 Aluminum Hot Products

7050 Aluminum Alloy Product Forms

Form Application
7050 Aluminum Sheet Aircraft skins, wing panels, fuselage components
7050 Aluminum Plate Structural components requiring higher strength
7050 Aluminum Extrusions Complex aerospace structures, customized designs
7050 Aluminum Forgings Critical aerospace applications, landing gear components
7050 Aluminum Bar and Rod Structural components, fittings
7050 Aluminum Wire Specialized applications requiring lightweight strength

7050 Aluminum Alloy Physical Properties

Properties Metric
Density 2.6-2.8 g/cm3
Melting point 494°C
Tensile strength 515 MPa
Yield strength 455 MPa
Fatigue strength 240 MPa
Elastic modulus 70-80 GPa
Poisson's ratio 0.33
Elongation 11%
Thermal conductivity 180 W/mK

7050 Aluminum Alloy Composition

  • Zinc (Zn): 5.7-6.7%
  • Magnesium (Mg): 2.0-2.6%
  • Copper (Cu): 1.9-2.6%
  • Chromium (Cr): 0.04-0.15%
  • Manganese (Mn): 0.06-0.10%
  • Others (each): 0.05% max
  • Others (total): 0.15% max
  • Aluminum (Al): Balance

7050 aluminum alloy

7050 Aluminum Applications

  • Aircraft and other structures
  • Fuselage frames
  • Bulkheads
  • Wing skins
  • Military aircraft applications

Eq to 7050 Aluminum

  • AMS 4108
  • AMS 4201
  • ASTM B247
  • ASTM B316
  • QQ A-430
  • What is 7050 aluminum used for?
  • What is the difference between 7050 and 7075 alloy?
  • What is the difference between 6061 and 7050?
  • What is the difference between 7000 and 7050 aluminum?
  • 7050-t7451 aluminum properties
  • 7050-t7451 aluminum
  • 7050 t6 aluminum properties
  • 7050 t7451 aluminum manufacturer
  • 7050 t6 aluminum
  • 7050-t7451 aluminum plate
  • 7050 vs 7075 aluminum
  • 7050 aluminum sheet
  • 7050 aluminum plate

Latest Order for 7050 Aluminum

  • 7050 T7451 Aerospace Aluminum Plate Sheet
  • 7050 Aluminum Rivet Wire
  • 7050 T74511 T76511 Aerospace Aluminum Rod Bars
  • 7050 Aluminum Alloy Wire for Rivets
  • 7050 O T1 T3 T7451 T7651 Aerospace Aluminum Profile Extrusion
  • 7050 Aluminum Alloy Forgings for Armor
  • 7050 T74/T7452 Aerospace Grade Aluminum Forging

Aluminium Alloy Table

Al 1000 series (Pure) 1050, 1060, 1070, 1100, 1145, 1200, 1230, 1350
Al-Cu 2000 series 2011, 2014, 2017, 2024, 2124, 2219, 2319, 2397, 2519, 2524, 2618
Al-Mn 3000 series 3003, 3004, 3005, 3104, 3105
Al-Si 4000 series 4006, 4007, 4015, 4032, 4043, 4047, 4543
Al-Mg 5000 series 5005, 5019, 5050, 5052, 5059, 5083, 5086, 5154, 5182, 5252, 5356, 5454, 5456, 5754
Al-Mg-Si 6000 series 6005, 6010, 6013, 6060, 6061, 6063, 6065, 6082, 6101
Al-Zn 7000 series 7005, 7010, 7022, 7034, 7039, 7046, 7050, 7055, 7065, 7072, 7075
8000 series (Misc.) 8006, 8009, 8011, 8014, 8019, 8025, 8030, 8090, 8091, 8093, 8176

Related Topics: Aerospace Aluminum 7050 Aerospace Aluminum Plate Sheet 2024 Aerospace Aluminum Plate Sheet 7075 Aerospace Aluminum Plate Sheet 2219 Aerospace Aluminum Plate Sheet 2618 Aerospace Aluminum Plate Sheet Aircraft Aluminum
