7050 Aerospace Aluminum Plate Sheet

Stable Quality Complete Specifications , Reasonable Price

7050 aerospace aluminum plate has excellent corrosion resistance, weldability and formability, and has extremely high strength and hardness. Haomei Aluminum can produce AMS 4050 QQ-A-430 EN 3982 7050 aerospace aluminum plate.

Table of Contents
  1. 7050 aerospace aluminum plate sheet features
  2. 7050 aerospace aluminum plate sheet size
  3. 7050 aerospace aluminum plate sheet vs 7075
  4. 7050 aerospace aluminum plate sheet Chemical Composition
  5. 7050 aerospace aluminum plate sheet Typical Mechanical Properties
  6. 7050 aerospace aluminum plate sheet applications
    1. 7050 aluminum plate for aviation industry
    2. 7050 aluminum plate for aerospace industry
  7. 7050 aerospace aluminum plate sheet processing technology

7050 is currently the most commonly used alloy for aviation main structural parts. Basically, when you see 7050 T7451, you know it is an aviation material. It can be said that 7050 alloy is a typical second-generation aviation aluminum alloy.

Alloy 7050 aluminum plate is now more commonly used in aerospace applications than 7075, especially in the 3-6 inch thickness range, because it retains strength in thicker sections.

7050 Aerospace Aluminum Plate Sheet

7050 aerospace aluminum plate sheet features

  • High Strength: Alloy 7050 has extremely high tensile strength, making it ideal for manufacturing materials requiring high strength.
  • Corrosion Resistance: This aluminum alloy performs well in a variety of environmental conditions and is highly resistant to corrosion.
  • Weldability: 7050 alloy has good weldability under appropriate conditions, making it easy to process during manufacturing.

7050 aerospace aluminum plate sheet size

  • Thickness: Available in a variety of thicknesses, from thin to thick. Common thicknesses are 1mm, 2mm, 5mm, 10mm, etc.
  • Width: The width of the board or sheet can vary according to customer requirements, but is usually in the range of 1000mm - 1500mm.
  • Length: Length can be customized according to application requirements, standard length range is 2000mm to 6000mm.
ALLOY TEMPER THICKNESS (MM) WIDTH(MM)
7050 T7451 4-260 1200-3800
T7651 4-260 1200-3800

7050 aerospace aluminum plate sheet vs 7075

  • 7075 is AlZn5.6Mg2.5Cu1.6Cr0.23 and 7050 is AlZn6.2Cu2.4Mg2.3Zr0.12. The main alloy difference is the use of "Zr" instead of "Cr".
  • 7050 T7451 (AMS 4050), which has slightly lower levels than 7050 T7651 (AMS 4342), has better SCC resistance and excellent flaking resistance.
  • 7050 T7451 exhibits better toughness, corrosion resistance and resistance to stress corrosion cracking than Alloy 7075. Because it is less sensitive to quenching than most other aerospace alloys, 7050 maintains its strength properties better than other high-strength alloys in thicker sections and more consistently throughout the thickness range in heavier gauges processing.
  • 7050 aerospace aluminum plate sheet features

7000 Series aluminum alloys have long been the first choice for aerospace and aircraft applications. The 7xxx series offers designers extremely high strength, lower manufacturing costs and lower replacement risk, making it the alloy of choice for applications where strength is a primary requirement.

The main alloying element of 7050 aerospace alloy is zinc. In addition to 3%-7.5% Zn, Mg can be added to obtain MgZn2, which has a significant strengthening effect and has a better heat treatment effect than Al-Zn alloy.

7050 thick aluminum plate has the characteristics of high strength, high toughness, fatigue resistance, and damage resistance. It is an indispensable key material for various key structural parts in the aerospace field. It can maintain overall flatness and no deformation after asymmetric processing.

7050 aerospace aluminum plate sheet Chemical Composition

ALLOY 7050
SI 0.12
FE 0.15
CU 2.0-2.6
MN 0.1
MG 1.9-2.6
CR 0.04
ZN 5.7-6.7
ZR 0.08-0.15
TI 0.06
STANDARD GB/AMS/EN

7050 aerospace aluminum plate sheet Typical Mechanical Properties

Material Temper Thickness Tensile Strength (ksi) Yield Strength (ksi) Elongation in 2" %
Alloy 7050 Plate T7451 <2.0 74 64 10
Alloy 7050 Plate T7451 2.0 -3.0 73 63 9
Alloy 7050 Plate T7451 3.0 - 4.0 72 62 9
Alloy 7050 Plate T7451 4.0 - 5.0 71 61 9
Alloy 7050 Plate T7651 0.25 - 1.0 76 66 9
Alloy 7050 Plate T7651 1.0 - 1.5 77 67 9
Alloy 7050 Plate T7651 1.5 - 2.0 76 66 9
Alloy 7050 Plate T7651 2.0 - 3.0 76 66 8

7050 aerospace aluminum plate sheet applications

7050 aluminum plate for aviation industry

7050 alloy is widely used in the manufacturing of aircraft structures, wings, landing gear and other components. Its high strength and lightweight characteristics allow the aircraft to improve performance while reducing the overall weight.

7050 aluminum plate for aerospace industry

7050 alloy also plays an important role in spacecraft, satellites and spacecraft components. It can withstand extreme temperatures and mechanical stress, ensuring the reliability and stability of the spacecraft.

7050 T7451 aluminum plate is widely used in the aerospace industry for applications requiring minimal maintenance and consistent, optimal strength. It is commonly used on bulkheads, fuselage frames and similar aircraft components.

Alloy 7050 has high corrosion resistance and maintains strength over wide cross-sections, making it more resistant to fracture than other alloys. It is commonly used in wing skins and fuselages, especially military aircraft.

7050 aerospace aluminum plate sheet processing technology

The manufacture of 7050 Aerospace Aluminum Plate Sheet involves multiple processing processes, including:

1. rolling

Through the rolling process, the aluminum alloy material is formed into the required plate or sheet shape.

2. Heat treatment

7050 alloy usually requires a heat treatment process to achieve the required mechanical properties. This includes steps such as aging.

3. Cutting and processing

Depending on the specific application needs, the panels may need to be cut, formed and machined to meet the aircraft or spacecraft design requirements.

  • AMS 4050: 7050-T7451 Plate
  • AMS 4107: 7050-T74 Die Forging
  • AMS 4108:7050-T7452 Hand Forgings
  • AMS 4201: 7050-T7651 Plate
  • AMS 4333: 7050-T7452 Forgings
  • AMS 4340: 7050-T76511 Extrusions
  • AMS 4341: 7050-T73511 Extrusions
  • AMS 4342: 7050-T74511 Extrusions
