6082 Aluminum Alloy

6082 is a heat-treatable strengthenable alloy with good formability, weldability, and machinability. It also has medium strength and can still maintain good operability after annealing.

Table of Contents
  1. 6082 Aluminum Alloy Advantages
  2. Haomei Aluminum 6082 Aluminum Hot Products
  3. 6082 Aluminum Alloy Product Features
  4. 6082 Aluminum Alloy Product Forms
  5. Corresponding Grades of 6082 Aluminum Alloy
  6. Aluminium 6082 Chemical Composition
  7. Aluminium 6082 Physical Properties
  8. Related Questions for 6082 Aluminum
  9. 6082 Aluminum Related Topics
  10. 6082 Aluminum Related Searches
  11. Aluminium Alloy Table

6082 and 6061 are both aluminum-magnesium-silicon heat-treatable strengthened alloys with good extrusion processing and forging properties, as well as good anodizing and corrosion resistance.

6082 Aluminum Alloy Advantages

  • 1. Good formability and weldability
  • 2. High strength
  • 3. Good usability and excellent interface features
  • 4. Easy to process and easy to coat
  • 5. Good corrosion resistance and oxidation resistance

Haomei Aluminum 6082 Aluminum Hot Products

6082 Aluminum Alloy Product Features

  • 6082 aluminum is typically formed by extrusion and rolling
  • Not for casting
  • Can be forged and clad, not common
  • Not work hardenable
  • Typically heat treated to produce a stronger but less ductile state

6082 Aluminum Alloy Product Forms

  • 6082 Aluminum Sheet
  • 6082 Aluminum Plate
  • 6082 Aluminum Coil
  • 6082 Aluminum Extrusions
  • 6082 Aluminum Tube
  • 6082 Aluminum Bar/Rod
  • 6082 Aluminum Forgings
  • 6082 Aluminum Wire
  • 6082 Aluminum Disc
  • 6082 Aluminum Strip

6082 Aluminium Alloy

Corresponding Grades of 6082 Aluminum Alloy

  • National standard: 6082 GB/T 3190-1996
  • ISO: Al SiMgMn ISO 209.1-1989
  • Non-standard: 64430 IS 733-2001 IS 737-2001
  • Russian standard: AII35/1350 ROCT 4785-1974
  • EN: EN AW-6082/AlSiMgMn EN 573-3-1994
  • German standard: AlMgSi/3.2315 DIN1725.1-1986/W-Nr
  • French standard: 6082 (A-SGMO0.7) NF A50-411 NF A50-451
  • American Standard: 6082/A96082 AA/UNS

Aluminium 6082 Chemical Composition

Element Weight Percentage (%)
Aluminium 95.2 to 98.3
Chromium 0.25 % max.
Copper 0.1 % max.
Iron 0.5 % max
Magnesium 0.6 to 1.2%
Manganese 0.4 to 1.0 %
Silicon 0.7 to 1.3%
Titanium 0.1 % max
Zinc 0.2 % max
residuals 0.15 % max

Aluminium 6082 Physical Properties

Properties Value
Density 2.71 gm/cc
Young's modulus 71 GPa
Ultimate tensile strength 140 to 330 MPa
Yield strength 260 MPa
Thermal Expansion 23.1 μm/m-K.
  • What is 6082 Aluminium alloy used for?
  • What is the difference between 6061 and 6082?
  • What is the difference between 7075 and 6082?
  • Is 6082 Aluminium bendable?
  • 6082 T6/T651 Aerospace Grade Aluminum Sheet Plate
  • 6082 T6/T4 Aerospace Grade Aluminum Forgings
  • 6082 T6 Aviation Aluminum Bar
  • 6082 T4 T6 T651 Aluminum Bar
  • 6082 T5 T6 Automotive Aluminum Extrusion
  • 6082 T6 Aerospace Aluminum Pipe Tube
  • 6082 Aluminum Round Bar
  • Marine Grade 6082 Aluminum Hexagonal Bar
  • 6082 O T6 Marine Aluminum Square Bar
  • 6082 Marine Aluminum Round Bars
  • 6082 T4 T5 T6 Electrical Aluminum Busbar
  • 6082 T6 T651 Aluminum Sheet
  • 6082 Aluminium Tubes & Pipes
  • 6082 T6/T651 Aerospace Aluminum Extrusions Profile
  • 6082 T6 Aluminum Forging for Automotive
  • Automotive 6082 Aluminum Wheel Hub Forging Supplier
  • 6082 T6 Aerospace Aluminum Wire
  • 6082 T4/O Automotive Aluminum Coil Strip Sheet
  • 6082t6 grade aluminium
  • 6082t6 grade aluminium properties
  • 6082 t651 aluminium properties
  • 6082 grade aluminium
  • 6082 t6 aluminium
  • 6082 t6 aluminium mechanical properties
  • 6082 vs 5083 aluminium
  • 6082 t6 aluminium properties
  • 6082 marine grade aluminium
  • 6082 aluminium

Aluminium Alloy Table

Al 1000 series (Pure) 1050, 1060, 1070, 1100, 1145, 1200, 1230, 1350
Al-Cu 2000 series 2011, 2014, 2017, 2024, 2124, 2219, 2319, 2397, 2519, 2524, 2618
Al-Mn 3000 series 3003, 3004, 3005, 3104, 3105
Al-Si 4000 series 4006, 4007, 4015, 4032, 4043, 4047, 4543
Al-Mg 5000 series 5005, 5019, 5050, 5052, 5059, 5083, 5086, 5154, 5182, 5252, 5356, 5454, 5456, 5754
Al-Mg-Si 6000 series 6005, 6010, 6013, 6060, 6061, 6063, 6065, 6082, 6101
Al-Zn 7000 series 7005, 7010, 7022, 7034, 7039, 7046, 7050, 7055, 7065, 7072, 7075
8000 series (Misc.) 8006, 8009, 8011, 8014, 8019, 8025, 8030, 8090, 8091, 8093, 8176
