5754 Aluminum Plate Sheet for Tank Truck

Strict Quality Control Stable Performance and Safety

Strictly control the quality of 5754 aluminum plates to ensure the production of high-quality 5754 tank car aluminum plates that meet industry performance and safety requirements.

Table of Contents
  1. What is 5754 Aluminum Plate, and Why is it used in Tank Trucks?
  2. Properties of 5754 Tanker Aluminum Plate
  3. Typical Dimensions of 5754 Tanker Aluminum Plate
  4. 5754 Tanker Aluminum Plates Typical Thicknesses
  5. 5754 Tank Truck Aluminum Plate Specifications
  6. Mechanical Properties of 5754 Tank Car Aluminum Plate
  7. 5754 Tank Car Aluminum Plate Quality Control
  8. Application of 5754 Aluminum Plate on Tank Car
    1. Tank Truck Body
    2. Tank Truck Bulkheads
    3. Tank Truck End Caps
    4. Tank Truck Liners
  9. Chemical Composition of 5754 Tank Truck Aluminum Plate
  10. Frequently Asked Questions (FAQs) about 5754 Aluminum Plate for Tank Trucks

What is 5754 Aluminum Plate, and Why is it used in Tank Trucks?

5754 aluminum is a widely used alloy known for its excellent corrosion resistance, strength, and weldability. It is commonly used in tank truck construction due to its ability to withstand exposure to various liquids and gases without corroding or degrading.

5754 Aluminum is a versatile and commonly used alloy used in a variety of industrial applications, including tank truck construction. This alloy has excellent corrosion resistance, weldability and machinability, making it an ideal material for tank truck construction.

5754 Aluminum

5754 aluminum is a reliable and durable material for tank truck applications, and when selecting 5754 tank aluminum sheet, it is important to consider the specific requirements of the application.

  • The thickness of the sheet will also depend on the specific requirements of the tanker and what it is carrying.
  • The surface finish helps prevent corrosion and makes tank trucks easier to clean.

Properties of 5754 Tanker Aluminum Plate

Key properties of 5754 aluminum include high corrosion resistance, good strength, excellent weldability, and a smooth surface finish. These properties make it ideal for tank trucks, which often transport corrosive or hazardous materials.

Typical Dimensions of 5754 Tanker Aluminum Plate

5754 aluminum plates for tank trucks are available in various dimensions, including standard sheet sizes. Common dimensions include 4' x 8', 4' x 10', and custom-cut sizes to meet specific tank requirements.

5754 Tanker Aluminum Plates Typical Thicknesses

Common thicknesses for 5754 aluminum plates used in tank trucks typically range from 4.0 mm to 12.0 mm (0.1575 inches to 0.4724 inches). The choice of thickness depends on factors such as the type of cargo, tank design, and regulatory requirements.

5754 Tanker Aluminum Plate Typical Thicknesses

Product Thickness (mm) Thickness (inches)
5754 Tanker Aluminum Plate 4 0.1575
5754 Tanker Aluminum Plate 5 0.1969
5754 Tanker Aluminum Plate 6 0.2362
5754 Tanker Aluminum Plate 8 0.315
5754 Tanker Aluminum Plate 10 0.3937
5754 Tanker Aluminum Plate 12 0.4724

5754 Tank Truck Aluminum Plate Specifications

  • Status : H32 and H111 are the tempering states commonly used for tank truck aluminum plates.
  • Thickness : 2mm - 12mm, the thickness may vary according to the specific application and customer requirements.
  • Width and Length : The width and length of the aluminum sheet may also vary depending on the specific application and customer requirements. However, the maximum width and length of the board is usually determined by available equipment and shipping considerations.
  • Surface Finish : Common surface finishes include satin finish, brushed finish and anodizing.
  • Quality Standard : ASTM, EN or GB, etc.

Mechanical Properties of 5754 Tank Car Aluminum Plate

Temper H32 H111
Tensile Strength (MPa) 160 - 215 135 - 185
Yield Strength (MPa) 80 - 140 65 - 120
Elongation (%) 12 - 20 15 - 25
Hardness (HB) 44 - 50 40 - 46

5754 Tank Car Aluminum Plate

5754 Tank Car Aluminum Plate Quality Control

5754 aluminum alloy is widely used in the structure of tank trucks due to its excellent corrosion resistance, weldability and machinability.

Chemical composition control : During the production process, the chemical composition of 5754 aluminum alloy is strictly controlled to ensure that the required alloying elements exist in the correct proportion.

  • Rolling Process Control : Closely monitor control measures such as roll speed, rolling force and temperature to ensure uniform thickness and smooth surface finish.
  • Heat Treatment Control : strictly control the heat treatment process to ensure the required tempering state. (H32 or H111)
  • Surface Quality Control : Minimize surface defects such as scratches, pits and cracks, so as not to affect the corrosion resistance and mechanical properties of the sheet. The surface quality of aluminum sheet is critical to its performance in tank truck applications.
  • Ultrasonic Flaw Detection : Ultrasonic flaw detection is often used to detect internal defects such as voids, inclusions, and cracks in aluminum plates. This is critical to ensuring that plates meet industry quality and safety standards.

5754 Aluminum Plate on Tank Car

Application of 5754 Aluminum Plate on Tank Car

5754 aluminum plate is widely used in the construction of tank trucks due to its excellent corrosion resistance, weldability and machinability. Some specific applications of 5754 aluminum plate on tank trucks include :

Tank Truck Body

5754 aluminum sheet is commonly used in the construction of tank truck bodies due to its high strength-to-weight ratio and excellent resistance to chemicals and other substances.

  • Status : H111 or H32
  • Thickness : 6-12mm
  • Surface treatment : polished or brushed

Tank Truck Bulkheads

Tank Truck Bulkheads are used to separate different compartments inside a tank truck. 5754 aluminum sheet is commonly used for bulkheads due to its excellent strength and corrosion resistance.

  • Status : H111, H32
  • Thickness : 6-12mm
  • Specific surface treatments such as satin or brushed finish.

Tank Truck End Caps

Tank Truck End Caps must be strong enough to withstand the pressure of the contents being transported. 5754 aluminum plate is strong and durable, making it an ideal material for end caps.

  • Status : H111, H32
  • Thickness : 6-12mm
  • The specification may also include specific finishes such as satin or brushed finishes.

Tank Truck Liners

The excellent corrosion resistance of 5754 aluminum makes it a popular choice for tank truck linings that are in direct contact with the contents of the transport.

  • Status : H32
  • Thickness : 2-5mm
  • The specification may also include specific surface treatments, such as smooth or non-slip surfaces.

It is important to note that the above specifications are general guidelines and that the specific condition and specification of 5754 aluminum used in tank truck construction may vary depending on the specific requirements of the application and industry standards.

5754 Tank Truck Aluminum Plate

The use of 5754 aluminum sheet in tank truck construction helps ensure reliable and durable transportation solutions for a wide range of industries including chemical, petroleum and food processing.

Chemical Composition of 5754 Tank Truck Aluminum Plate

Element Composition (%)
Aluminum (Al) 96.8
Magnesium (Mg) 2.6
Manganese (Mn) 0.4
Chromium (Cr) 0.3
Iron (Fe) 0.4
Silicon (Si) 0.4
Copper (Cu) 0.1
Zinc (Zn) 0.2
Titanium (Ti) 0.15
Other Elements <0.05 (each), <0.15 (total)

Frequently Asked Questions (FAQs) about 5754 Aluminum Plate for Tank Trucks

How is 5754 Aluminum Plate Processed and Fabricated for Tank Truck Manufacturing?

5754 aluminum plates can be cut, bent, and welded using standard metal fabrication techniques. Manufacturers typically cut the plates to the required dimensions, shape them to fit the tank design, and weld the seams to create the tank structure.

Is 5754 Aluminum Suitable for Transporting Specific Types of Chemicals or Liquids?

5754 aluminum is known for its general corrosion resistance, but the suitability for specific chemicals or liquids depends on factors such as the concentration, temperature, and exposure duration. Compatibility testing and consultation with materials experts are advisable for transporting specific chemicals.

Can 5754 Aluminum Plates be Coated for Added Protection?

Yes, 5754 aluminum plates can be coated with various protective coatings to enhance their resistance to corrosion and improve durability. Coatings such as epoxy or polymer linings may be applied to the interior of the tank for specific applications.

Are there any Considerations for Maintenance and Inspection of Tanks made with 5754 Aluminum?

Regular maintenance and inspections are crucial to ensure the integrity of aluminum tank trucks. Inspections should include checking for signs of corrosion, leaks, and structural integrity. Any issues should be addressed promptly to maintain safety and compliance.
