What are Aluminum Strips for Shutters?
Aluminum Strip is widely used in the manufacture of shutters. Aluminum strips are lighter than traditional wood or plastic materials, making them easier to install and hang. Aluminum strips have a smooth surface, are easy to wipe, do not accumulate dust and dirt, are not easy to deform and fade, Make the blinds more durable.
Aluminum Strip for Shutters, so it can resist the erosion of sunlight, wind, rain and dust, and it is safe and firm, favored by many people. Aluminum Strip for Shutters can be made of various aluminum alloy materials:
- 3003 Aluminum Strip for Shutters
- 5052 Aluminum Strip for Shutters
- 3005 Aluminum Strip for Shutters
- 3105 Aluminum Strip for Shutters
Aluminum Strip for Shutters Advantages
- Lightweight and high-strength : Aluminum alloy has low density and high strength, which can reduce the weight of the product while ensuring the strength, and is suitable for large-area products such as large blinds.
- Corrosion resistance : There is an oxide film on the surface of the aluminum alloy, which can resist corrosion well and make the shutters have a long service life.
- Beautiful and generous : the aluminum alloy can be surface treated by coating, painting, etc., which makes the appearance of the blinds more beautiful and generous.
- Easy processing and forming : aluminum alloy has good plasticity and processing performance, and can be processed by stamping, deep drawing, bending, etc., and is suitable for shutters of various shapes and sizes.
- Recyclable : Aluminum alloy can be recycled and reused through smelting, which is conducive to resource conservation and environmental protection
Aluminum Strip for Shutters Specifications
| Property | Specification |
|---|---|
| Aluminum Grades | 3004, 3005, 5052 H19 |
| Thickness Range (mm) | 0.125-0.25 |
| Width Range (mm) | 15-100 |
| Diameter (mm) | 300 |
| Surface Treatment | Color Coated |
| Color | Any color |
| Yield Strength (MPa) | ≥ 50 |
| Ultimate Strength (MPa) | ≥ 100 |
| Elongation (%) | ≥ 8 |
| Certifications | SGS, ISO9001, MSDS |
The specifications of aluminum strips used for shutters can vary based on the type of shutter, its intended application, and the manufacturer's offerings. Here are some common specifications that you might find for aluminum strips used in shutter construction:
- Thickness: The thickness of aluminum strips can range from around 0.2 mm to 2.5 mm, depending on the shutter's design and intended use.
- Width: The width of aluminum strips can vary widely based on the shutter type, from narrow strips for louvers to wider strips for rolling shutters.
- Length: Lengths can be customized based on shutter dimensions and requirements. Standard lengths often range from a few feet to several meters.
- Surface Finish: Aluminum strips can have different surface finishes, including mill finish (unaltered), anodized finishes, or painted/powder-coated finishes for aesthetics and protection.
- Edge Treatment: Depending on the manufacturer and shutter design, the edges of the aluminum strips might be chamfered, rounded, or left straight.
- Insulation and Coating: For certain applications, aluminum strips might have insulating coatings applied to enhance energy efficiency or noise reduction.
- Tensile Strength: Tensile strength can vary based on the alloy used. It's usually in the range of 140-240 MPa for common aluminum alloys.
- Color and Appearance: Aluminum strips can be offered in various colors and finishes to match architectural designs and aesthetics.
| Aluminum Strip | Typical Width (mm) |
|---|---|
| Aluminum Strip for Shutters | 15 |
| Aluminum Strip for Shutters | 16 |
| Aluminum Strip for Shutters | 25 |
| Aluminum Strip for Shutters | 35 |
| Aluminum Strip for Shutters | 50 |
| Aluminum Strip for Shutters | 89 |
| Aluminum Strip for Shutters | 92.5 |
| Aluminum Strip for Shutters | 112 |
| Aluminum Strip | Typical Thickness (mm) |
|---|---|
| Aluminum Strip for Shutters | 0.16 |
| Aluminum Strip for Shutters | 0.18 |
| Aluminum Strip for Shutters | 0.21 |
| Aluminum Strip for Shutters | 0.24 |
Appearance Quality Requirements for Shutter Aluminum Strips
- 1. The surface is not allowed to have defects such as color difference, cracks, corrosion, unevenness, peeling, perforations, bubbles, pressure wounds, scratches, metal and non-metal indentations, imprints, pine branches, straightening roller marks, etc.
- 2. The aluminum strip should be cut neatly, and there should be no cracks, burrs, ruffles, edge deformation or waves that affect the paint.
- 3. No joints are allowed in the aluminum strips of blinds
Dimensional Tolerances of Aluminum Strips for Shutters
| Width/mm | Width tolerance/mm | Thickness/mm | Thickness tolerance/mm |
|---|---|---|---|
| 12.50-50.00 | ±0.05 | 0.120-0.180 | ±0.003 |
| >50.00-100.00 | ±0.10 | ＞0.180-0.250 | ±0.005 |
| >100.00-1250.00 | ±1.00 | ＞0.250-0.500 | ±0.007 |
Surface Roughness of Aluminum Strips for Shutters
| Width /mm | Wave height/mm | Wave per meter length |
|---|---|---|
| 12.5-100.0 | ≤0.5 | ≤3 |
| >100.0-1250.0 | ≤3.0 | ≤3 |
Side Curvature of Aluminum Strip for Shutters
| Width/mm | Any 2000mm length upper side curvature / mm |
|---|---|
| 12.5-50.0 | ≤2.0 |
| >50.0-100.0 | ≤0.5 |
Aluminum Strip for Shutters Categories
Aluminum Strip for Shutters can be classified according to different classification methods, the following are some common classification methods :
- Alloy classification : Classify according to the different aluminum alloys used in aluminum strips, such as commonly used aluminum alloys such as 3003, 5052, and 6061.
- Surface state classification : Classify according to the state of the surface of the aluminum strip, such as coated and uncoated aluminum strip.
- Processing technology classification : Classify according to the processing technology that the aluminum strip has undergone, such as cold rolling, hot rolling, deep drawing and other aluminum strips.
- Use classification : Classify according to the different uses of aluminum strips, such as for the manufacture of indoor shutters, outdoor shutters, large shutters or windows.
- Aluminum strips are widely used in the manufacture of shutters, and are generally made of aluminum alloy with good formability and corrosion resistance. Here are some
Aluminum Strip for Shutters Application
- 3003 aluminum strip : often used to make indoor shutters, with good formability and processing performance, smooth surface, and can be coated according to needs.
- 5052 aluminum strip : used to make outdoor shutters, its high strength and excellent corrosion resistance can ensure long-term use without deformation and rust.
- 6061 aluminum strip : used to make large blinds that require high strength and rigidity. It has high hardness, high strength, and excellent oxidation resistance, which can meet the requirements of long-term use.
When choosing an aluminum strip suitable for making shutters, in addition to considering the cost and processing performance of the material, it is also necessary to choose the appropriate alloy type and thickness according to the specific use environment and requirements
Hot sold Aluminum Strip for Shutters
3003 Aluminum Strip for Shutters
Generally, aluminum strips in O, H12, H14, H16 and other states are used.
Specifications are generally
- Thickness 0.2-3.0mm
- The width is below 1000mm
- 3003-O aluminum strip : the thickness is 0.5mm, the width is 800mm, used to make indoor shutters.
5052 Aluminum Strip for Shutters
Generally, aluminum strips in H32, H34, H36 and other states are used, and the specifications are generally
- Thickness 0.2-4.0mm
- The width is below 1000mm
- 5052-H32 aluminum strip : thickness 1.0mm, width 600mm, used to manufacture outdoor shutters.
6061 Aluminum Strip for Shutters
Generally, aluminum strips in T6 state are used, and the specifications are generally
- Thickness 0.2-6.0mm
- The width is below 1000mm
6061-T6 aluminum strip : thickness 3.0mm, width 800mm, used to make large shutters or windows.
Frequently Asked Questions about the Aluminum Strip for Shutters
Do Aluminum Strips for Shutters Require Maintenance?
Aluminum's corrosion resistance reduces the need for extensive maintenance. However, occasional cleaning to remove dirt and debris can help maintain their appearance.
What is the Typical Lifespan of Shutters Made with Aluminum Strips?
Shutters made with aluminum strips can have a long lifespan due to aluminum's corrosion resistance. Proper installation and occasional maintenance can further extend their durability.
Are these Strips Easy to Install?
Yes, aluminum strips for shutters are lightweight and easy to handle, which simplifies the installation process. They can be cut, shaped, and assembled to fit various shutter designs.
What Finishes are Available for Aluminum Strips used in Shutters?
Aluminum strips for shutters can be finished with various coatings, including powder coatings, anodizing, and paint, to achieve desired colors and surface properties.
Can Aluminum Strips be used for Motorized Shutter Systems?
Yes, aluminum strips can be integrated into motorized shutter systems, allowing for automated control and operation of the shutters.
Are Aluminum Strips Environmentally Friendly?
Yes, aluminum is highly recyclable, and using aluminum products contributes to sustainable practices within the construction and design industry.
